The R33 Skyline
The specifications of the Nissan Skyline model R33
![](r33/blackuglygtr.html) |
![](r33/bluer33.html) |
![](images/er33gtstype-g.gif) |
<
R33SKYLINE engine principal statistics
|
Type
|
RB25DET
|
RB25DE
|
RB20E
|
Type * number of cylinders
|
DOHC * 6 cylinder
|
DOHC * 6 cylinder
|
OHC * 6 cylinder
|
Cylinder bone x distance
|
86.0×71.7
|
86.0×71.7
|
78.0×69.7
|
Entire
aerodynamic volume displacement
|
2498
|
2498
|
1998
|
Compression ratio
|
9.0
|
10.0
|
9.5
|
The highest
output PS/rpm
|
250/6400
(245/6400)
|
190/6400
(TypeS-200/6400)
|
130/5600
|
Engine
torque
|
|
190/6400
(TypeS-200/6400)
|
130/5600
|
Fuel feeder kgm/rpm
|
The NISSAN
EGI (ECCS)
Electrically controlled gasoline injection
device
|
The NISSAN EGI (ECCS)
Electrically
controlled gasoline injection device
|
The NISSAN EGI
(ECCS)
Electrically controlled gasoline injection device
|
Use fuel
Tank capacity
|
Unleaded
premium gasoline
65 liter
|
Unleaded premium
gasoline
65 liter
|
Unleaded regular
gasoline
65 liter
|
|
|
![](#) |
|
![](r33withactivelsd2door_files/spacer.html) |
![](r33withactivelsd2door_files/spacer.html) |
Engine |
Engine type |
RB25DET |
Type |
Inline 6
cylinder DOHC 24 valve IC turbo |
Bore × stroke |
86mm×71.7mm |
Displacement |
2498cc |
Compression ratio |
9:1 |
Fuel
system |
The
NISSAN EGI (ECCS)
Electrically controlled gasoline injection device |
Max power |
184kW @ 6400rpm |
Max
torque |
294Nm @
4800rpm |
Supercharger |
IC equipped turbo |
Fuel tank
capacity |
65
litres |
Fuel type |
Unleaded premium gasoline |
Fuel
consumption |
9.8
l/100km |
LEV approved |
No |
Transmission |
Type |
OD attaching 5 speed floor shift |
Drive
layout |
FR |
Limited slip differential |
Standard on turbo models option on others |
|
|
![](r33withactivelsd2door_files/spacer.html) |
![](r33withactivelsd2door_files/spacer.html) |
Steering and Suspension |
Steering type |
Power assisted rack & pinion |
Front
suspension |
Independent
suspension multiple link system |
Rear suspension |
Independent suspension multiple link
system |
Front
brakes |
Ventilated
disk |
Rear brakes |
Ventilated disk |
Front
tyres |
205/55r16
89v |
Rear tyres |
225/50R16 92v |
Turning
circle |
10.4
m |
Dimensions |
Exterior length |
4640mm |
Exterior
width |
1720mm |
Exterior height |
1340mm |
Interior
length |
820mm |
Interior width |
1415mm |
Interior
height |
1090mm |
Wheelbase |
2720mm |
Front
track |
1480mm |
Rear track |
1460mm |
Ground
clearance |
145mm |
Weight |
1390kg | |
![](#) |
![](#) |
![](#) |
![](#) |
![](#) |
Exterior |
Front fog lamps |
No |
Rear fog
lamps |
No |
Xenon headlights |
No |
Projector
headlights |
No |
Front spoiler |
No |
Rear
spoiler |
Standard |
Rear window wiper |
Standard |
Safety |
Driver airbag |
Option |
Front
passenger airbag |
Option |
Side airbags |
No |
Anti-lock
braking system |
Standard |
Traction control |
No |
Front seat
belt pre-tensioners |
No |
Front seat belt force limiters |
No |
Rear seat lap
sash belt |
Standard |
Child seat attachment |
No |
Side impact
protection bars |
Standard | |
|
![](#) |
![](#) |
Navigation and Audio |
Navigation |
Option |
Sound (CD and
MD) |
AM/FM radio,
CD player |
CD player |
No |
Features |
Air conditioning |
Automatic |
Power
windows |
Standard |
Central door locking |
Standard |
Steering
wheel reach adjust |
No |
Steering wheel height adjust |
Standard |
Cruise
control |
No |
Leather steering wheel |
Standard |
Leather
seats |
No |
Power front seat adjustment |
No |
Power rear
seat adjustment |
No |
Wood panel |
No |
Sunroof |
No |
Alloy wheels |
16 inch standard |
Split fold
rear seatback |
No |
Ultraviolet reducing glass |
No |
Tinted
windows |
No | |
R33SKYLINE 2 door grade summary
|
Grade name (prior-term * mid-term * latter-term * all period)
|
Type (drive system) |
Engine |
GTS25t |
ECR33 (FR)
|
RB25DET
|
GTS25t |
ECR33 (FR)
|
RB25DET
|
GTS25t |
ECR33 (FR) |
RB25DET |
GTS25t |
ECR33 (FR)
|
RB25DET
|
GTS25t
|
ECR33 (FR) |
RB25DET |
GTS25 |
ECR33 (FR)
|
RB25DE
|
GTS25 (previous term)
|
ER33 (FR) |
RB25DE |
GTS |
HR33 (FR)
|
RB20E
|
GTS (latter term)
|
HR33 (FR) |
RB20E |
GTS urban liner
S |
HR33 (FR)
|
RB20E
|
GTS urban liner |
HR33 (FR) |
RB20E |
GTS -4 (all period)
|
ENR33 (4WD)
|
RB25DE
| |
R33SKYLINE 4 door grade summary
|
Grade name (prior-term * mid-term * latter-term * all period)
|
Type (drive system) |
Engine |
GTS25t
|
ECR33 (FR) |
RB25DET |
GTS25t |
ECR33 (FR)
|
RB25DET
|
GTS25t |
ECR33 (FR)
|
RB25DET
|
GTS25 |
ER33 (FR)
|
RB25DE
|
GTS25 |
ER33 (FR) |
RB25DE |
GTS25 |
ER33 (FR)
|
RB25DE
|
GTS25 |
ECR33 (FR) |
RB25DE |
GTS25
|
ER33 (FR)
|
RB25DE
|
GTS25 |
ER33 (FR) |
RB25DE |
GTS25 (previous term)
|
HR33 (FR)
|
RB25DE
|
GTS Type-S (latter term)
|
HR33 (FR) |
RB20E |
GTS Type-X LImited (latter term)
|
HR33 (FR)
|
RB20E
|
GTS Type-X (latter term)
|
HR33 (FR) |
RB20E |
GTS Type-G (prior-term * mid term)
|
HR33 (FR)
|
RB20E
|
GTS Type-XG 40th |
HR33 (FR) |
RB20E |
GTS Type-XG (prior-term * mid term)
|
HR33 (FR)
|
RB20E
|
GTS (all period)
|
HR33 (FR) |
RB20E |
GTS-4 Type-XG
40th |
ENR33 (4WD)
|
RB25DE
|
GTS-4 |
ENR33 (4WD) |
RB25DE |
GTS-4 (all
period) |
ENR33 (4WD)
|
RB25DE
| |
You do not call mid-term type
excessively, but it is easy to understand, the sea urchin using, it
increases. |
